IP67 design 12V 24V 100W waterproof power supply Chinese factory price

Home > Products > IP67 design 12V 24V 100W waterproof power supply Chinese factory price

IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price
IP67 design 12V 24V 100W waterproof power supply Chinese factory price

IP67 design 12V 24V 100W waterproof power supply Chinese factory price


Input AC 200-240V, 50/60Hz Output DC  12V  8. 33ADC  24V4. 16A 100W
Warranty 3 Years IP Level IP67 Waterproof
Housing Aluminum Housing OEM YES
Protections Short Circuit, Over Load, Over Voltage Working Temperature -20~40°C
Type Constant Voltage, Single Output. Non Dimmable
High Light WHOOSH 100W 12V 24V LED DriverIP67 Waterproof Power SupplyIntegrated  housing with silicone fully sealedUsing 105℃ Long lifespan electrolytic capacitors



Product Details

Model Number

HXS-100S-12/24

LeadTime

Within 48 Hours: for regular stock models

Brand Name

WHOOSH / OEM

1-2 weeks: for OEM orders

Place of Origin

Hunan,China

Warranty

3 Years

MOQ

100PCS/Model

Sample Policy

Free samples 1-3PCS/Model

Customized Cost

Customized sticker/printing for free; Customized boxes for free >1000pcs each;

Payment Terms

T/T, Western Union,Money Gram

Supply Ability

22,000pcsper day

Aftersales

< 0.3% according to statistics collected;

Replacement against defective products pictures or more application details if needed

Ports support

Guangzhou, Shenzhen, Shanghai, Ningbo, Yi Wu, other mainland ports

Price

With detailed inquiry, Accurate quotation can be emailed within 24 hours;

Inquiry to: whooshpower@gmail.com



Product Description
Product Specification
1) Sepcifications

Model

Size/mm

Input

Output

Output Current

Warranty

HXS-100S-12

201*45*34

AC 200-240V

DC12V

8.33A

3 Year

HXS-100S-24

DC24V

4.17 A

2) Input Characteristics

Input Voltage: AC 200-264V

Input Frequency: 50/60Hz

Input Current: 1.5A Max (full loaded at the lower limited of input voltage range)

Inrush Current:57AMax. Cold start at 240Vac input, with rated load and 25℃ ambient.

Ac Leakage Current:0.75mA Max. At 240Vac input

3) Output Characteristics

1. Output Power

Voltage

Min. Load

Rated Load

Peak@10mS

Output power

12V

0A

8.33A

120W

100W

24V

0A

4.17 A

120W

100W



2. Line Regulation

Voltage

Min. Load

Rated Load

Line Regulation

Load Regulation

12V

0A

8.33A

±3%

±5%

24V

0A

4.17 A

±3%

±5%



3. Ripple and Noise

Under nominal voltage and nominal load,the ripple and noise are as follows when measure with Max.Bandwidth of 20MHz and Parallel 47uF/0.1uF,crossed connected at testing point.

Voltage

Ripple and Noise(Max.)

12V

200mV p-p

24V

200mV p-p

4. Turn on delay time: 2Second Max.at 220Vac input and output Max.load.

5. Rise time: 10mS Max.at 240Vac input and output Max load.

6. Efficiency: 12V 87%Min; 24V 89%Min, At 220Vac input voltage and full load calculation efficiency.

7. Overshoot: 10% Max. When power supply at turn or turn off.

4) Protection Functions:

1. Short circuit protection: auto recovered when short circuit faults remove.

2. Over current Protection: auto recovered when over current faults remove.

3. Over load protection: auto recovered when over current faults remove.

5)Test

Drop test, Salt Spray Test, Surge test, Ageing test, lightning test, Temperature Variation test etc.

6) Safety Requirement

EMC/EMI

1.Safety Standard:

Safety: Design by : EN55032B,Class B Standards

2.Insulation resistance:100MΩmin at 500V DC
7) EMI& EMCRequirement

Designed according to the following standards:

1.GB17625.1; EN61000-3-2,-3

2.EN55024; EN61000-4-2,3,4,5,6,8,11

8Structurer




HXS-S Series Specification

Model No.

Size/mm

Efficency

Output current

PF

Output Volt

Input Volt

HXS-60S-12

163*38*28

84%

5.0A

0.5

12V DC

200240Vac

HXS-60S-24

87%

2.5A

0.5

24V DC

200240Vac

HXS-100S-12

201*45*34

87%

8.33A

0.5

12V DC

200240Vac

HXS-100S-24

89%

4.17A

0.5

24V DC

200240Vac

HXS-150S-12

236*45*34

88%

12.5A

0.5

12V DC

200240Vac

HXS-150S-24

90%

6.25A

0.5

24V DC

200240Vac

HXS-200S-12

221*59.4*37

88%

16.7A

0.5

12V DC

200240Vac

HXS-200S-24

90%

8.33A

0.5

24V DC

200240Vac

HXS-300S-12

241*59.4*37

89%

25A

0.5

12V DC

200240Vac

HXS-300S-24

91%

12.5A

0.5

24V DC

200240Vac

HXS-300S-36

91%

8.33A

0.5

24V DC

200240Vac

HXS-400S-12

286*71.4*43

88%

33.3A

0.5

24V DC

200240Vac

HXS-400S-24

91%

16.6A

0.5

24V DC

200240Vac



9) OEM

Customize label and Inner box

 10) Packing details Pack in a big brown carton outside and a box or a bubble bag per piece inside. (Or negotiate when order).



11)Shipping



12)Company Information

Hunan Huaxin (WHOOSH) Electronic Technology Co., Ltd.has specialized in LED AC to DC power supply manufacturing since 2004, located in Hunan province, in the central south of China. We have 6 production lines and 400 people in factory with 10,000 square meter, including the R&D team.

We have manufactured all kinds of LED power supply used for LED Sign, LED Advertising, LED Illumination, LED Screen, LED lightbox; CCTV Device, Industial Automation Facility, Electronic Communication Device, Medical Care Equipment, etc.

WHOOSH has passed ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.

What's more, defective rate is less than 1% within 2 years.



--We are on exhibitions!

Each year we have 3-4 domestic exhibitions (ISLE, SIGN CHINA, SHANGHAI LIGHT EXPO etc.) and 2-3 overseas exhibitions ( Asian, Middle East etc.)



--Honor & Certifications:

ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.
