Slim Power Supply 24V 150W Semi-potted Interior for LED lights

Home > Products > Slim Power Supply 24V 150W Semi-potted Interior for LED lights

Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights
Slim Power Supply 24V 150W Semi-potted Interior for LED lights

Slim Power Supply 24V 150W Semi-potted Interior for LED lights


Input

AC 180-240V, 50/60Hz

Output

DC12V 12.5A

DC24V 6.25A

Warranty

3 Years

IP Level

IP65

Housing

AluminumHousing

OEM

YES

Protections

Short Circuit, Over Load, Over Voltage

Working Temperature

-20~40°C

Type

Constant Voltage, Single Output. Dimmable



High Light

Semi-potted interior

Suitable for narrow space

Long lifespan electrolytic capacitors

 SC, OV, OL protections





Product Details

Model Number

HX-150GCL-12/24

LeadTime

Within 48 Hours: for regular stock models

Brand Name

WHOOSH / OEM

1-2 weeks: for OEM orders

Place of Origin

Hunan,China

Warranty

3 Years

MOQ

100PCS/Model

Sample Policy

Free samples 1-3PCS/Model

Customized Cost

Customized sticker/printing for free; Customized boxes for free >1000pcs each;

Payment Terms

T/T, Western Union,Money Gram

Supply Ability

22,000pcsper day

Aftersales

< 0.3% according to statistics collected;

Replacement against defective products pictures or more application details if needed

Ports support

Guangzhou, Shenzhen, Shanghai, Ningbo, Yi Wu, other mainland ports

Price

With detailed inquiry, Accurate quotation can be emailed within 24 hours;

Inquiry to: whooshpower@gmail.com



Product Description
Product Specification

AC180-264V to DC24V 4.16A 150Slim Power Supply

1) Sepcifications

Model

Size/mm

Input

Output

Output Current

Warranty

HX-150GCL-12

280*46.5*30

AC180-264V

DC12V

12.5A

3 Years

HX-150GCL-24

280*46.5*30

DC24V

6.25A

3 Years

2) Input Characteristics

Input Voltage: AC 200-240V

Input Frequency: 50/60Hz

Input Current: 1.0A Max (full loaded at the lower limited of input voltage range)

Inrush Current:45 Amps Max. Cold start at 240Vac input, with rated load and 25℃ ambient.

Ac Leakage Current: 0.75mA Max. At 240Vac input

3) Output Characteristics

1. Output Power

Output Volt

Min. Load

Rated Load

Peak@10mS

Rated Output Power

12V

0A

12.5A

180W

150W

24V

0A

6.25A

180W

150W

2. Line Regulation

Output Volt

Min. Load

Rated Load

Line Regulation

Load Regulation

12V

0A

12.5A

±3%

±5%

24V

0A

6.25A

±3%

±5%

3. Ripple and Noise

Under nominal voltage and nominal load,the ripple and noise are as follows when measure with Max.Bandwidth of 20MHz and Parallel 47uF/0.1uF,crossed connected at testing point.

Output Volt

Ripple and Noise(Max.)

12V

120mV p-p

24V

120mV p-p

4. Turn on delay time: 2Second Max.at 220Vac input and output Max.load.

5. Rise time:80 mS Max.at 240Vac input and output Max load.

6. Efficiency:12V 87% Min; 24V 88%Min, At 220Vac input voltage and full load calculation efficiency.

7. Overshoot: 10% Max.When power supply at turn or turn off.

4) Protection Functions:

1. Short circuit protection: auto recovered when short circuit faults remove.

2. Over current Protection: auto recovered when over current faults remove.

3. Over load protection: auto recovered when over current faults remove.

5)Test

Drop test, Salt Spray Test, Surge test, Ageing test, lightning test, Temperature Variation test etc.

6)Safety Requirement

1.Safety Standard:

Safety: Design by GB4943-1 standard.

2. Iusulation resistance: Primary to secondary:100MΩ min at 500V DC.

7) EMI Requirement

Designed according to the following standards:

1. EN55022B, Class B rules

2. GB17625.1;EN61000-3-2,-3

3. EN55024;EN61000-4-2,3,4,5,6,8,11

8)  Structurer


9) OEM

Customize label and Inner box

 10) Packing details Pack in a big brown carton outside and a box or a bubble bag per piece inside. (Or negotiate when order).

11)Shipping

12)Company Information

Hunan Huaxin (WHOOSH) Electronic Technology Co., Ltd.has specialized in LED AC to DC power supply manufacturing since 2004, located in Hunan province, in the central south of China. We have 6 production lines and 400 people in factory with 10,000 square meter, including the R&D team.

We have manufactured all kinds of LED power supply used for LED Sign, LED Advertising, LED Illumination, LED Screen, LED lightbox; CCTV Device, Industial Automation Facility, Electronic Communication Device, Medical Care Equipment, etc.

WHOOSH has passed ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.

What's more, defective rate is less than 1% within 2 years.

--We are on the exhibitions!

Each year we have 3-4 domestic exhibitions (ISLE, SIGN CHINA, SHANGHAI LIGHT EXPO etc.) and 2-3 overseas exhibitions ( Asian, Middle East etc.)

--Honor & Certifications:

ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.
