12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting

Home > Products > 12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting

12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting
12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting

12V 200W Rainproof Mini power supply Special bevel terminal designs easier for wire connecting


Input

AC180-240V, 50/60Hz

Output

DC12V 5A 60W

DC12V 10A 120W

DC12V 16.6A 200W



Warranty

2 Years

IP Level

IP65

Housing

Aluminum Housing

OEM

YES

Protections

Short Circuit, Over Load, Over Voltage

Working Temperature

-20~40°C

Type

Constant Voltage, Single Output. Dimmable



High Light

WHOOSH300W12VLED DriverIntelligent over load protectionLong lifespan electrolytic capacitorsSemi-potted interior-40℃workable



Product Details

Model Number

XRF-60/120/200-12

LeadTime

Within 48 Hours: for regular stock models

Brand Name

WHOOSH / OEM

1-2 weeks: for OEM orders

Place of Origin

Hunan,China

Warranty

3 Years

MOQ

100PCS/Model

Sample Policy

Free samples 1-3PCS/Model

Customized Cost

Customized sticker/printing for free; Customized boxes for free >1000pcs each;

Payment Terms

T/T, Western Union,Money Gram

Supply Ability

22,000pcsper day

Aftersales

< 0.3% according to statistics collected;

Replacement against defective products pictures or more application details if needed

Ports support

Guangzhou, Shenzhen, Shanghai, Ningbo, Yi Wu, other mainland ports

Price

With detailed inquiry, Accurate quotation can be emailed within 24 hours;

Inquiry to: whooshpower@gmail.com



Product Description
Product Specification
1) Sepcifications

Model

Size/mm

Input

Output

Output Current

Warranty

XRF-60-12

112.5*75*42

AC 200-240V

DC12V

5A

2 Years

XRF-120-12

191.5*74*42

DC12V

10A

2 Years

XRF-200-12

143.6*100.6*50.6

DC12V

16.6A

2 Years

2) Input Characteristics

Input Voltage: AC 200-240V

Input Frequency: 50/60Hz

Input Current: 60W 0.6A; 120W 1.5A; 200W 2.3A Max (full loaded at the lower limited of input voltage range)

Inrush Current:60W 50A; 120W 70A; 200W 80AMax. Cold start at 240Vac input, with rated load and 25℃ ambient.

Ac Leakage Current:3.5mA Max. At 240Vac input

3) Output Characteristics

1. Output Power

Rated Output Power

Min. Load

Rated Load

Peak@10mS

60W

0A

5A

72W

120W

0A

10A

144W

200W

0A

16.6A

240W



2. Line Regulation

Rated Output Power

Min. Load

Rated Load

Line Regulation

Rated Output Power

Load Regulation

60W

0A

5A

±3%

72W

±5%

120W

0A

10A

±3%

144W

±5%

200W

0A

16.6A

±3%

240W

±5%

3. Ripple and Noise

Under nominal voltage and nominal load,the ripple and noise are as follows when measure with Max.Bandwidth of 20MHz and Parallel 47uF/0.1uF,crossed connected at testing point.

Rated Output Power

Ripple and Noise(Max.)

60W

200mV p-p

120W

200mV p-p

200W

380mV p-p

4. Turn on delay time:60W 3Second; 120W 200W2Second Max.at 220Vac input and output Max.load.

5. Rise time: 60W40 400mS Max.at 240Vac input and output Max load.

6. Efficiency: 60W 80%Min; 120W 86%Min; 200W 83%Min, At 220Vac input voltage and full load calculation efficiency.

7. Overshoot:60W10% Max;120W 200W 15%Max. When power supply at turn or turn off.

4) Protection Functions:

1. Short circuit protection: auto recovered when short circuit faults remove.

2. Over current Protection: auto recovered when over current faults remove.

3. Over load protection: auto recovered when over current faults remove.

5)Test

Drop test, Salt Spray Test, Surge test, Ageing test, lightning test, Temperature Variation test etc.

6)Safety Requirement

1.Safety Standard:

Safety: Design by IEC60950 standard.


2.DIELECTRIC STRENGTH Hi-Pot:

RatedOutput power

60W

120W

200W

Primary to secondary

1200Vac/10mA/60S

for type test

1500Vac/10mA/60S

for type test

1200Vac/10mA/60S

for type test

Primary to case

1200Vac/10mA/60S for type test

1200Vac/10mA/60S for type test

1200Vac/10mA/60S for type test

Secondary to case

300Vac/10mA/60S

for type test

300Vac/10mA/60S

for type test

300Vac/10mA/60S

for type test

7) EMI Requirement

Designed according to the following standards:

  1. FCCClassB

  2. EN55022 ClassB

  3. GB9254-1998,GB17625.1-2003

8)  Structurer




OEM

Customize label and Inner box

 10) Packing details Pack in a big brown carton outside and a box or a bubble bag per piece inside. (Or negotiate when order).

11)Shipping

12)Company Information

Hunan Huaxin (WHOOSH) Electronic Technology Co., Ltd.has specialized in LED AC to DC power supply manufacturing since 2004, located in Hunan province, in the central south of China. We have 6 production lines and 400 people in factory with 10,000 square meter, including the R&D team.

We have manufactured all kinds of LED power supply used for LED Sign, LED Advertising, LED Illumination, LED Screen, LED lightbox; CCTV Device, Industial Automation Facility, Electronic Communication Device, Medical Care Equipment, etc.

WHOOSH has passed ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.

What's more, defective rate is less than 1% within 2 years.

--We are on exhibitions!

Each year we have 3-4 domestic exhibitions (ISLE, SIGN CHINA, SHANGHAI LIGHT EXPO etc.) and 2-3 overseas exhibitions ( Asian, Middle East etc.)

--Honor & Certifications:

ISO9001:2015 (certified by SGS) Quality Management System, Korea KC certification, EU CB Certification, CE, ROHS, CCC, EMS, LVD, IP67 Waterproof Level Certifications etc.
